Double Stage Sliding Vane Rotary Vacuum Pump (2X-4, 2X-8, 2X-15, 2X-30, 2X-70) , Liquid (water) Ring Vacuum Pump, Oil-Free Vertical Piston Vacuum Pump
Application 2X Sliding Vane Rotary Vacuum Pump is one of the basic equipment for obtaining vacuum for airtight container
Send your inquiryDESCRIPTION
Basic Info
Model NO. | 2X |
Theory | Vacuum Pump |
Impeller | Single-Stage Pump |
Type | Liqui Ring |
Material | Cast Iron/Stainless Steel |
Transport Package | Wooden Case |
Trademark | SUOTO |
Origin | Shanghai, China |
HS Code | 8414100090 |
Production Capacity | 20, 000 PCS/Year |
Product Description
Application2X Sliding Vane Rotary Vacuum Pump is one of the basic equipment for obtaining vacuum for airtight containers by exhausting gas. It can be used alone, or used as the fore pump in front of the booster pump, diffusion pump, molecular pump, etc. This pump is applicable to the vacuum metallurgy, vacuum welding, vacuum impregnation, coating, vacuum drying, as well as the vacuum treatments in chemical and pharmaceutical industry, electric vacuum devices and other industries.
Notices
1. The pump can work within the ambient temperature range of 5~40 and under the inlet pressure less than 1330PA. It is also allowable for long-term continuous work.
2. The pump is neither applicable to pump the gases which have excessive oxygen content, poisonous and explosive feature, corrosive effects to etals and chemical reactions with oil of pumps, and dust particles, nor act as a transfer pump to transfer gas form one container to another.
3. The continuous working hours of the pump under the inlet air pressure of 6000PA shall not exceed 3min to avoid damages caused by oil injection or bad lubrication.
Model | 2X-4A | 2X-8A | 2X-8 | 2X-15 | 2X-30A | 2X-70A |
(L/S) Pumping Speed | 4 | 8 | 8 | 15 | 30 | 70 |
(≤ Pa) Ultimate Pressure | ≤ 6× 10 -2 | |||||
(kw) Motor Power | 0.55 | 1.1 | 1.1 | 2.2 | 3 | 5.5 |
(Degrees C) Temperature Rise | ≤ 4 Degrees C | |||||
dB(A) LW Noise | ≤ 75 | ≤ 78 | ≤ 78 | ≤ 80 | ≤ 82 | ≤ 86 |
(mm) Inlet Diameter | Φ 25 | Φ 25 | Φ 40 | Φ 40 | Φ 65 | Φ 80 |
(rpm) Rotational Speed | 450 | 550 | 320 | 320 | 450 | 420 |
(L) Injection Amount of Oil | 0.7 | 0.9 | 2 | 2.8 | 2 | 4.2 |
(cm) Size | 55× 34× 41 | 55× 43× 44 | 79× 43× 54 | 79× 53× 54 | 78× 50× 56 | 91× 65× 70 |
(Kg) Weight | 54 | 70 | 135 | 196 | 240 | 428 |
Related Products
-
Factory Customized Agricultural Watch Farmland Irrigation Filter System
-
Lab Disposable Plastic Sterile 1ml 2ml 5ml 10ml 50ml Serological Pipette Serological Pipette Lab Medical Measuring Sterile 1ml 2ml 5ml 10ml 25ml 50ml Lab
-
Levo Plus Laboratory Large Volume Electronic Pipette Filler
-
Large Photochemical Mixed Glass Reactor Made in China
